SMART FLIP DOWN TV CEILING MOUNT powered by Tuya PLB-M0546AI Support most 32" ~ 70" TVs from china(chinese)

PLB-M0546AI

SMART FLIP DOWN TV CEILING MOUNT powered by Tuya

Support most 32" ~ 70" TVs

Description

LUMI’s PLB-M0544AI Smart Flip Down TV Ceiling Mount is a perfect choice to save space or for room with low ceiling. A quality motor holds TVs up to 32" ~ 70" and lowers and retracts TVs smoothly and quietly, completely controllable by remote or Tuya app (AI series). A balanced mechanism prevents any ceiling vibrations when the TV is in motion. There are convenient memory settings as well — a brilliant choice for public or home TV viewing installations!

Tag:

Add to Inquiry

Add to Compare

View Series

Duty Calculator

FEATURES

●Flip Down Design: allows for easy storage, cleared up space and out-of-way safety
●Powerful Motor: more stable, strong and durable
●App Remote Control: remote powered by Tuya App
●Built-In Level Adjustment: ensures perfect positioning

Flip Down Design: allows for easy storage, cleared up space and out-of-way safety
Powerful Motor: more stable, strong and durable
App Remote Control: remote powered by Tuya App
Built-In Level Adjustment: ensures perfect positioning

SPECIFICATIONS

Product Category:	Motorized TV Ceiling Mount
Rank:	Standard
Material:	Plastic,Steel
Metal Sheet Thickness:	VESA Panel THK=2mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet,Bracket Arm THK=2mm cold-rolled sheet (VESA Panel THK=0.079" cold-rolled sheet,Wall Plate THK=0.079" cold-rolled sheet,Bracket Arm THK=0.079" cold-rolled sheet)
Surface Finish:	Powder Coating
Color:	Matte Black,Matte White
Dimensions:	710x664x516mm (28"x26.1"x20.3")
Fit Screen Size:	32"-70"
Fit Curved TV:	Yes
Mounting Hole Pattern :	VESA Only
VESA Compatible:	200x100,200x200,300x200,200x400,400x200,300x300,400x300,400x400,600x400
Max. Mounting Hole:	600x400
Weight Capacity:	35kg (77lbs)
Strength Tested:	3 Times Approved
Profile:	108mm (4.3")

Tilt Range:	0~-75°
Screen Level:	+2°~-2°
Screen Freely Tilting:	No
Installation:	Ceiling Mounted
Panel Type:	Detachable Panel
Wall Plate Type:	Fixed Wall Plate
AV Component Shelf:	No
Cable Management:	Yes
Anti-theft:	No
Power Supply:	Input：AC 100~240V,50/60Hz；Output：DC 24V, 1.5A
Power Cord Length:	1.5m (4.9ft)
Controller Type:	Application Control,Radio Frequency(RF) Remote
Bubble Level:	No
Accessory Kit Package:	Compartment Polybag,Normal/Ziplock Polybag
Certification:	CE,FCC

Product Category:	Motorized TV Ceiling Mount
Rank:	Standard
Material:	Plastic,Steel
Metal Sheet Thickness:	VESA Panel THK=2mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet,Bracket Arm THK=2mm cold-rolled sheet (VESA Panel THK=0.079" cold-rolled sheet,Wall Plate THK=0.079" cold-rolled sheet,Bracket Arm THK=0.079" cold-rolled sheet)
Surface Finish:	Powder Coating
Color:	Matte Black,Matte White
Dimensions:	710x664x516mm (28"x26.1"x20.3")
Fit Screen Size:	32"-70"
Fit Curved TV:	Yes
Mounting Hole Pattern :	VESA Only
VESA Compatible:	200x100,200x200,300x200,200x400,400x200,300x300,400x300,400x400,600x400
Max. Mounting Hole:	600x400
Weight Capacity:	35kg (77lbs)
Strength Tested:	3 Times Approved
Profile:	108mm (4.3")

Tilt Range:	0~-75°
Screen Level:	+2°~-2°
Screen Freely Tilting:	No
Installation:	Ceiling Mounted
Panel Type:	Detachable Panel
Wall Plate Type:	Fixed Wall Plate
AV Component Shelf:	No
Cable Management:	Yes
Anti-theft:	No
Power Supply:	Input：AC 100~240V,50/60Hz；Output：DC 24V, 1.5A
Power Cord Length:	1.5m (4.9ft)
Controller Type:	Application Control,Radio Frequency(RF) Remote
Bubble Level:	No
Accessory Kit Package:	Compartment Polybag,Normal/Ziplock Polybag
Certification:	CE,FCC
